 HPE  Proliant ML110 G4 QuickSpecs Flag US QuickSpecs
Folder-Closed ML110 G4 HDD SSD Folder-Closed ML110 G4 Processors Folder-Closed ML110 G4 Memory
Folder-Closed ML110 G4 Controllers Folder-Closed ML110 G4 Networking Folder-Closed ML110 G4 Power
Folder-Closed ML110 G4 Quickspecs Folder-Closed ML110 G4 Quickspecs Folder-Closed ML110 G4 Options New  Refurb
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Proliant ML110 G4 Overview

HP ProLiant ML110 Generation 4 (G4)

Proliant ML110 G4 Front View:Proliant ML110 G4 Rear View:
1. CD-ROM Drive1. Power Supply Outlet
2.Power LED2.S/2 Mouse Port
3.Drive Activity LED3.PS/2 Keyboard Port
4.Well ventilated chassis design4.Serial Ports A,B
5.Main System Board5.VGA Port
6.HDD controller card (Optional)6.Rear USB 2.0 Ports
7.HP LO 100c Management Card (Optional)7.LAN Port (RJ-45)
8.Rear System Fan8.HP Lights-Out 100 Remote Management Card Port
9.370W Power Supply

What's New
  • Processors:
    • Dual-Core Intel® Pentium D Processor 935 (3.2 GHz, 800 MHz FSB)
    • Dual-Core Intel® Pentium D Processor 945 (3.4 GHz, 800 MHz FSB)
  • Storage Controller:
    • HP SC44Ge Host Bus Adapter
  • Communications:
    • HP NC110T PCI Express Gigabit Server Adapter
  • Internal Storage:
    • Support up to 1.2TB SAS max storage (4 x 300 GB)

At A Glance

  • Processor:
    • Dual-Core Intel® Xeon® processors 3000 sequence
    • Dual-Core Intel® Pentium® D processors 800 or 900 sequence
    • Single-Core Intel® Celeron® D processors
  • ML110 G4 Memory
    • 512 MB Standard / 8 GB Maximum of PC2-5300 DDR2 667 MHz ECC unbuffered Memory
  • Storage Controller:
    • 4 Port SATA controller with Embedded RAID on Motherboard
    • HP 8 Internal Port SAS HBA with RAID
  • Internal Drive Support:
    • 4 HDD Support:
      • 2TB SATA max storage (utilizing 500GB CTO HDD)
      • 1.2TB SAS max storage (4 x 300GB)
  • Network Controller:
    • Embedded NC320i PCIe Gigabit Server Adapter
  • Expansion Slots:
    • Two 32-bit/33MHz PCI at 3.3V slot
    • Two PCI-Express slots (x4 and x8, both in an x8 connector).
  • USB Ports:
    • Six total USB ports (2 internal, 2 front, 2 rear)
  • Form Factor:
    • Micro ATX tower
  • Management:
    • Standard IPMI reporting
    • Lights Out 100c Remote Management Card (Optional)
  • Warranty:
    • Protected by HP Services and a worldwide network of HP Authorized Channel Partners, including a one-year, limited warranty, Next Business Day 1, year on-site limited Global warranty. Certain restrictions and exclusions apply. SATA hard drives have a one year warranty
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Standard Features

NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and specifications, please visit: https://h71028.www7.hp.com/ERC/downloads/4AA0-7780ENW.pdf
Processor
One of the following depending on Model
Dual-Core Intel® Pentium® D Processor 945 (3.4 GHz, 800 MHz FSB)*
Dual-Core Intel® Pentium® D Processor 935 (3.2 GHz, 800 MHz FSB)*
Dual-Core Intel® Pentium® D processor 925 (3.0 GHz, 800MHz, FSB)
Dual-Core Intel® Pentium® D processor 915 (2.8 GHz, 800MHz FSB)
Dual-Core Intel® Pentium® D processor 820 (2.8 GHz, 800MHz FSB)*
Dual-Core Intel® Xeon® processor 3050 (2.13 GHz, 1066MHz FSB)*
Dual-Core Intel® Xeon® processor 3040 (1.86 GHz, 1066MHz FSB)
Single-Core Intel® Celeron® D processor 352 (3.20 GHz, 533MHz FSB)*
*Available through Configure To Order only. See Factory Integration Models section for more details.

Cache Memory
One of the following depending on Model
1x2 MB shared Level 2 cache (Xeon sequence)
2x2 MB Level 2 cache (Pentium D 900 sequence)
2x1 MB Level 2 cache (Pentium D 800 sequence)
512KB Level 2 cache (Celeron D)

Chipset Intel 3000

Memory Protection ECC

ML110 G4 Memory Type PC2-5300 unbuffered DDR2 SDRAM (667MHz)
Standard 512 MB
Maximum 8 GB

Network Controller Embedded NC320i PCIe Gigabit Server Adapter

Expansion Slots
Slot
Number
Bus Speed
Hot Plug Y/N
PCI Voltage
Notes
4
x8 PCI Express
No
n/a
Full Height
3
x4 PCI Express
No
n/a
In a x8 slot
Full Height
1/2
32bit/33MHz PCI
No
3.3V
Full Height
NOTE: Only one brace for full length cards provided.

Storage Controller
One of the following depending on Model
Integrated 4 port SATA controller with embedded RAID

Storage CD-ROM 48x IDE (ATAPI) CD-ROM Drive
Hard Drives SATA 160GB SATA 7750 rpm Drive
SAS 72GB SAS 15,000 rpm Drive

Maximum Internal Storage Type
SAS
(Not-hot plug)
1.2TB (4x300GB)
SATA
(Non-hot plug)
2TB (4 x 500GB*)
*Available through Configure To Order only. See Factory Integration Models section for more details.

Interfaces Parallel 0
Serial 2
Pointing Device (Mouse, PS2) 1
Graphics 1
Keyboard (PS2) 1
USB

6 total (2 rear, 2 front panel, 2 internal (one for USB Tape connectivity))

NOTE: Internal USB ports are optimal for the attachment of HP USB DAT Tape Drives
NOTE: Please see the following URL for additional information regarding USB support:
https://h18004.www1.hp.com/products/servers/platforms/usb-support.html

Network RJ-45 (Ethernet) 1
Management Optional Lights-Out 100c Remote Management port

Graphics Integrated 2MB video controller

Form Factor Micro ATX Tower (4U)

Industry Standard Compliance ACPI V2.0 Compliant
PCI 2.3 Compliant
PXE Support
WOL Support
IPMI 2.0 compliance

Manageability Embedded IPMI standard reporting
Optional HP ProLiant Lights-Out 100c Remote Management Card

Security Power-on password
Setup password

Server Power Cords 12' country specific, lowline NEMA power cord.
NOTE: Rack models ship standard with a 12' IEC cable. Most redundant power supply options ship with a 6' country specific power cord. Localized cables included with geographic specific models in other world regions.

Power Supply 370 Watts

System Fans 1 – non-redundant system fan shipped standard
1 – non-redundant CPU heatsink fan shipped standard

OS SupportMicrosoft Windows Server 2003: Standard & Enterprise Edition (32 and 64 bit)
Microsoft Windows Small Business Server 2003
Microsoft Windows 2003 Server, Web Edition
Microsoft Windows Server 2008
Novell NetWare 6.5 SBS (only after SP6 release)
RedHat Enterprise Linux
SUSE Linux Enterprise Server
NOTE: For an up-to-date listing of the latest ML110 G4 OS support matrix, please see:
https://www.hp.com/go/supportos
NOTE: For an up-to-date listing of the latest software and drivers available for your server, please select your server: https://h20000.www2.hp.com/bizsupport/TechSupport/Product.jsp?lang=en&cc=
us&taskId=135&prodTypeId=15351&prodCatId=241435

NOTE: Drivers may also found on the base media for some Linux OS's. When configuring your server, please consult your base media driver base, or visit HP.com at: https://h18023.www1.hp.com/support/files/server/us/index.html
NOTE: For more Linux OS support & certification information, please visit our the ProLiant & Bladesystem Server Linux matrix: https://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE: When installing a Windows OS Environment and configuring the embedded SATA RAID, AHCI, or SAS controllers, installation of a driver from a diskette device is required. The optional USB floppy drive (part number DC361B) is required on the ML110 G4 to accomplish this operation.
NOTE: Netware 6.5 SP6 is not supported with the embedded SATA RAID.

Factory Express Portfolio for Servers and Storage

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and/or storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging and custom packaging HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers, as well as, the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to https://www.hp.com/go/factory-express.

HP Enterprise Configurator

The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.


Service and Support

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.

NOTE: Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support with next business day response. Additional information regarding worldwide limited warranty and technical support is available at: https://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

HP Care Pack Services provide total care and support expertise with committed response designed to meet your IT and business needs.

HP Care Pack services include coverage for the HP branded hardware options qualified for the server that are purchased at the same time or afterward and internal to the enclosure. It also includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Recommended Service - Simplify ProLiant solution implementation, maintenance and management.

  • Support Service -3 Year, 9x5 Next Business Day coverage, excluding HP holidays only
  • Deployment Service - Hardware Installation only

Enhanced Service - Optimize service level to increase IT performance and availability

  • Support Service - 3 Year 13x5 Same Business Day, 4-Hour response coverage
  • Deployment Service - Installation and Start-up only

Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays.

For a complete listing of service offerings and information visit:
https://www.hp.com/services/proliantservices
https://www.hp.com/go/proliant/carepack

contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Models

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory Integrated Models" section.
SATA Models
HP ML110G4 P925 512MB, NHP 160GB SATA (1P)
440288-001



Processor(s)
One of the following depending on Model
One (1) Dual-Core Intel® Pentium® D Processor 925 (3.0 GHz, 800 MHz FSB)
Cache Memory
One of the following depending on Model
2 x 2MB Level 2 cache (Pentium 915 & Pentium 925)
1 x 2MB shared Level 2 cache (Xeon 3040)
Memory 512 MB PC2-5300 ECC (DDR2-667Mhz) (1 x 512 MB)
Storage Controller HP Embedded 4 Port SATA Controller with embedded RAID
Hard Drive 160GB SATA HDD
Internal Storage Maximum 1TB (4 x 250GB) SATA
Optical Drive 48x CD-ROM
Form Factor Micro ATX Tower

SAS Models
HP ML110G4 3040, 512MB, NHP-SAS (1P)
432126-001
Processor(s)
One of the following depending on Model
One (1) Dual-Core Intel® Xeon® 3040 Processor (1.86 GHz, 1066 MHz FSB)
Cache Memory 1 x 2MB shared Level 2 cache (Xeon 3040)
Memory 512 MB PC2-5300 ECC (DDR2-667Mhz) (1 x 512 MB)
Storage Controller HP 8 Internal Port SAS HBA with RAID (0,1)
Hard Drive 72GB SAS HDD
Internal Storage Maximum 1.2TB (4 x 300GB) SAS
Optical Drive 48x CD-ROM
Form Factor Micro ATX Tower

Country Code Key XX=00 NA
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Configuration Information-Factory Integrated Models

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE: FIO indicates that this option is a Factory Installable Option.
Step 1: Base Configuration
Models HP ProLiant ML110 G4 Tower Chassis (North America)

417710-B21

Factory Integrated Models ship with:
Embedded NC320i PCIe Gigabit Server Adapter
Keyboard and Mouse
370 Watts, PFC (Power Factor Correcting)
Tower Form Factor (4U)

Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)
Processors Single-Core Intel® Celeron® D processor 352 3.20 GHz/533MHz/512 MB L2 Cache, Factory Integrated
430934-B21
Dual-Core Intel® Pentium® D processor 925 3.0 GHz/800MHz/2x2 MB L2 Cache, Factory Integrated 433357-B21
Dual-Core Intel® Pentium® D Processor 935 3.2 GHz/800 MHz, 2x2 MB L2 Cache, Factory Integrated 440284-B21
Dual-Core Intel® Pentium® D Processor 945 3.4 GHz/800 MHz/2x2 MB L2 Cache, Factory Integrated 440285-B21
Dual-Core Intel® Xeon® processor 3040 1.86 GHz/1066MHz/1x2M L2 Cache, Factory Integrated 432125-B21
Dual-Core Intel® Xeon® processor 3050 2.13 GHz/1066MHz/1x2M L2 Cache, Factory Integrated 430936-B21

Memory 2 GB Unbuffered PC2-5300 ECC DIMM (1 x 2 GB)
1 GB Unbuffered PC2-5300 ECC DIMM (1 x 1 GB) 432804-B21 432804-B21
512 MB Unbuffered PC2-5300 ECC DIMM (1 x 512 MB) 432803-B21 432803-B21

Hard DrivesSerial ATA (SATA) – Non-hot Plug HDD (SATA or SAS Models)
HP 80GB 1.5G SATA 7.2K NHP 3.5" HDD
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD411275-B21 411275-B21
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD411276-B21 411276-B21
HP 500GB 1.5G SATA 7.2K NHP 3.5" HDD, FIO*404469-B21
* Factory Integrated Only
Serial Attached SCSI (SAS) Non-Hot Plug (SAS Models Only)
HP 300GB SAS 3.5" 15K NHP 431950-B21 431950-B21
HP 146GB SAS 3.5" 15K NHP 432093-B21 432093-B21
HP 72GB SAS 3.5" 15K NHP432095-B21 432095-B21

Optical Drives CD-RW/DVD-ROM Combo Drive Option Kit
HP DVD+R/RW 8X HH
HP ProLiant 48X CD
398972-B21
DVD ROM Drive 16x
NOTE: For the installation of Windows and other OS's, a floppy drive (DC361B) may be required to complete driver installation. A USB drive key may not work to complete driver installation.

Step 3: Choose Additional Options for Factory Integration
NOTE: For additional options, please refer to the "Options" section below.
NOTE: Some options may not be factory integratable. Please contact your local sales representative for additional information.
Operating Systems
Pre-install Microsoft Windows 2003 SBS Standard Edition
MS W2003 SBS R2 Std 1XX FIO Eng SW
432564-xx1

MS W2003 SBS R2 Prm 1XX FIO Eng SW

432566-xx1

Country Code Key xx=00 NA
xx=01 Australia
xx=03 UK
xx=04 Germany
xx=05 France
xx=06 Italy
xx=07 Spanish
xx=20 Brazil
xx=21 Hungarian
xx=22 Czech
xx=24 Polish
xx=33 Dutch
xx=37 AP
xx=42 Euro
xx=AA PRC
xx=29 Japan
xx=AB Taiwan
xx=AD Korea
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Options

Memory 2 GB Unbuffered PC2-5300 ECC DIMM (1 x 2 GB)
1 GB Unbuffered PC2-5300 ECC DIMM (1 x 1 GB)
512 MB Unbuffered PC2-5300 ECC DIMM (1 x 512 MB)

Optical Drives CD-RW/DVD-ROM Combo Drive Option Kit
48X CD-ROM Option, Carbon
398972-B21
DVD-RW Drive Option Kit
1.44 MB USB Diskette Drive
DC361B
NOTE: For the installation of Windows and other OS's, a floppy drive may be required to complete driver installation. A USB drive key may not work to complete driver installation.

ML110 G4 Hard Drives Serial – ATA (SATA) – Non-Hot Plug (SATA Models Only)
HP 80GB 1.5G SATA 7.2K NHP 3.5" HDD
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD
NOTE: When purchasing systems with the 500GB Non-Hot Plug SATA drives, please reference the Configuration Information Section of this QuickSpecs to order via Configuration to Order.
NOTE: The purchase of additional SATA hard drives requires the purchase of additional HP 1-Port SATA RAID Cables, (P/N 413748-B21)

Serial Attached SCSI (SAS) Non-Hot Plug (SAS Models Only)
HP 300GB SAS 3.5" 15K NHP
HP 146GB SAS 3.5" 15K NHP
HP 72GB SAS 3.5" 15K NHP
NOTE: The purchase of SAS hard drives requires the purchase of HP Internal SAS/SATA 4-Port Cable (P/N 430479-B21). This cable is standard in the SAS BTO model.
NOTE: The purchase of SAS HBA or array controller is required.


Storage Controllers HP SC44Ge Host Bus Adapter
HP SC11Xe Host Bus Adapter
HP 8 Internal Port SAS HBA with RAID
NOTE: PCI-X Interface (PCI 32bit/33MHz compatible)
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
NOTE: PCI-X Interface (PCI 32bit/33MHz compatible)
HP Smart Array E200/128 BBWC Controller
128MB Battery-Backed Write Cache Enabler
NOTE: Supports the Smart Array E200 Controller, Smart Array 641 Controller and Smart Array 642 Controller.
HP 1-Port SATA RAID Cable
NOTE: The purchase of SATA hard drives requires the purchase of the HP 1-Port SATA RAID Cable (P/N 430479-B21) for each additional hard drive.
413748-B21
HP Internal SAS/SATA 4-Port Cable
NOTE:
The purchase of a SAS Storage Controller requires the purchase of HP SAS/SATA 4-Port Cable (P/N 430479-B21)
430479-B21
NOTE: SAS Storage Controllers will run both SATA and SAS drives.

Communications HP NC110T PCI Express Gigabit Server Adapter
NOTE: Does not support Windows 2000.
HP NC360T PCI Express Dual Port Gigabit Server Adapter
Agere 2006 PCI Hi-Speed 56K Modem
440519-B21

Tape Drives NOTE: Installation of SCSI internal tape drives in a ML110 G4 model requires SCSI controller kit
(PN: 412911-B21 412911-B21).
NOTE: For complete listing of tape drive offerings see: https://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
USB Tape Drives
HP StorageWorks DAT 40 USB Internal Tape Drive (Carbonite)
DW022A

HP StorageWorks DAT 72 USB Internal Tape Drive (Carbonite)

DW026A
HP StorageWorks DAT 160 USB Internal Tape Drive
Q1580A
SAS Tape Drives
HP StorageWorks DAT 160 SAS Internal Tape Drive
Q1587A
DAT SCSI Tape Drives
HP StorageWorks DAT 40 SCSI Internal Tape Drive (Carbon)
C5686C
HP StorageWorks DAT 72 SCSI Internal Tape Drive (Carbon)
Q1522B
HP StorageWorks DAT 160 SCSI Internal Tape Drive
Q1573A

HP D2D Backup System HP StorageWorks D2D110 Backup System
NOTE: 1TB of Disk Storage
EH880A
HP StorageWorks D2D110 Backup System with Data Protector Express Software Kit
NOTE: 1TB of Disk Storage
EH923A
HP StorageWorks D2D120 Backup System
NOTE: 2TB of Disk Storage
EH884A
HP StorageWorks D2D120 Backup System with Data Protector Express Software Kit
NOTE: 2TB of Disk Storage
EH924A

HP StorageWorks D2D130 Backup System
NOTE: 3TB of Disk Storage.

EH950A

HP StorageWorks D2D130 Backup System with Data Protector Express Software Kit
NOTE: 3TB of Disk Storage.

EH951A

HP StorageWorks D2D130 Backup System with LTO-3 Ultrium 920 SAS Tape Drive
NOTE: 3TB of Disk Storage.

EH952A

NOTE: Please see the HP D2D Backup Systems QuickSpecs for additional information:
https://h18000.www1.hp.com/products/quickspecs/12651_div/12651_div.HTML (Worldwide)


Installation of Server into Racks

ProLiant Rack Enabling Kit

417705-B21

Lights Out Management Card Lights-Out Management Card Kit for ML110 G4
418280-B21

UPS HP T1000 UPS, JPN/TWN
AF404A
HP T1000 UPS, NA
AF403A
HP T1000 UPS, INTL
AF405A
HP T750 UPS, Low Voltage (NA/JPN)
378439-D71
HP T750 UPS, High Voltage (INTL)
378439-B31

USB Options HP 1GB USB 2.0 Floppy Drive Key
442085-B21
HP 256MB USB 2.0 Floppy Drive Key
442084-B21
HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)
HP USB 04 Standard Keyboard
DT528A#xxx
USB 2.0 4-port HUB
DG954A

HP KVM Switch Options HP 1x4 Console Switch
HP PS2 Server Console Cable, 6 foot, 2-Pack
HP USB Server Console Cable, 6 foot, 2-Pack
NOTE: required for supporting USB peripherals.
NOTE: For additional information regarding KVM Switches, Serial Console servers, rack mount monitors, keyboards and all related options please see the following URL: https://www.hp.com/go/kvm.
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Service and Support, HP Care Pack, and Warranty Information

Service and Support Offerings
(HP Care Pack Services)
Hardware Services 4-Hour On-site Service
13-Hour x 5-Day Coverage, 3 Years
U4434E
24-Hour x 7-Day Coverage, 3 Years
U4435E
Hardware Services Next Business Day On-Site Service
9-Hour x 5-Day Coverage, 3 Years
U4433E
Hardware Services 6 Hour Call-to-Repair
24-Hour x 7-Day Coverage, 3 Years, 6 Hour Call-to-Repair
U4436E
Hardware Installation Service
HP Install ProLiant ML110 Service
U4444E
NOTE: For more information, customer/resellers can contact: https://www.hp.com/services/carepack.
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Memory

HP ProLiant ML110 G4 Models
Standard Memory
512 MB of PC2-5300 DDR2 SDRAM running at 512 MB with ECC capabilities Memory installed (1 x 512 MB SDRAM DIMM).
Standard Memory Plus Optional Memory
Up to 5120 MB memory is available with the optional installation of PC2-5300 un-buffered ECC DDR2 SDRAM DIMM Memory kits.
Standard Memory Replaced with Optional Memory
Up to 8192 MB of memory is available with the removal of the standard 512 MB of memory and the optional installation of PC2-5300 un-buffered ECC DDR2 SDRAM DIMM Memory kits.
NOTE: The below chart does not represent all possible memory configurations.
NOTE: In memory configurations requiring 2 DIMM and 4 DIMM configurations, the memory must be paired for optimal performance. This means that DIMMs in slot 1 and 3 have to be identical, in slot 2 and 4 have to be identical. (For example, the Optional memory configuration shown below)

ML110 G4 Memory
Slot

4
3
2
1
Standard 512 MB
Empty
Empty
Empty
512 MB
Optional 5120 MB
2048 MB
512 MB
2048 MB
512 MB
Maximum 8192 MB
2048 MB
2048 MB
2048 MB
2048 MB
Following are memory options available from HP:

2 GB Unbuffered PC2-5300 ECC DIMM (1 x 2 GB)

1 GB Unbuffered PC2-5300 ECC DIMM (1 x 1 GB)

512 MB Unbuffered PC2-5300 ECC DIMM (1 x 512 MB)

contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Storage

1
48x IDE (ATAPI) CD-ROM
2
Removable Media Bays (1.6" each)
3, 4, 5, 6
Four (4) Non-Hot Plug Drive Bays


Drive Support



Quantity
Supported

Position
Supported


Controller

Removable Media


DVD + CDRW Drive 2 1 or 2 Integrated IDE (ATAPI)
DVD-RW Drive 2 1 or 2 Integrated IDE (ATAPI)

ML110 G4 Hard Drives (SATA Models only)
SATA 1.5Gb – Non-Hot Plug


Quantity
Supported

Position
Supported


Controller

3.5-inch
80GB 7.2K, SATA
160GB 7.2K, SATA
250GB 7.2K SATA
500GB 7.2K SATA
Up to 4 3,4,5,6 4 Port SATA controller with Embedded RAID on Motherboard

ML110 G4 Hard Drives (SAS Models only)
SAS – Non-Hot Plug


Quantity
Supported

Position
Supported


Controller

3.5-inch
72GB 15K SAS
145GB 15K SAS
300GB 15K SAS
Up to 4 3,4,5,6 HP 8 Internal Port SAS HBA with RAID (0,1)

Maximum Storage Capacity – SATA/SAS Models
Internal SATA

1TB (4x250GB (BTO)
2TB (4 x 500GB (CTO)
SAS 1.2TB (4x300GB)
Total SATA

1TB (4x250GB (BTO)
2TB (4 x 500GB (CTO)
SAS 1.2TB (4x300GB)

Tape Drives and D2D Backup System
NOTE: A SCSI controller needs to be purchased to operate internal SCSI devices in the SATA Models.
NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the following:
https://h18000.www1.hp.com/products/quickspecs/Division/10233.html (Worldwide)


Position
Supported

Controller

Controller/HBA Option Kit Part Number

Internal USB Tape Drives
DAT 24 USB
DAT 40 USB
DAT 72 USB
2
USB 2.0 port
N/A

External USB Tape Drives
DAT 40 USB
DAT 72 USB
DAT160 USB

External
USB 2.0 port
N/A
Internal SAS Tape Drives
DAT 160 SAS
2
HP SC44Ge Host Bus Adapter
External SAS Tape Drives
DAT 160 SAS
External
HP SC44Ge Host Bus Adapter

Internal SCSI Tape Drives
DAT 40
DAT 72
DAT160

2
HP SC11Xe Host Bus Adapter

External SCSI Tape Drives
DAT 40
DAT 72
DAT160

External
HP SC11Xe Host Bus Adapter
HP StorageWorks D2D Backup Systems
D2D110
D2D120
External
Embedded Network Controller
N/A
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Power Specifications

Part Number 416121-001
Spare Kit 419029-001
Operational Input Voltage Range (Vrms) 100 to 127 and 200 to 240 V auto ranging
Frequency Range (Nominal) (Hz) 50 to 60 Hz




Nominal Input Voltage (Vrms)
100
115
208
220
230
240
Max Rated Output Wattage Rating
N/A
370
N/A
N/A
370
N/A
Nominal Input Current (A rms)
N/A
8
N/A
N/A
4
N/A
Max Rated Input Wattage Rating (Watts)
N/A
N/A
N/A
N/A
N/A
N/A
Max. Rated VA (Volt-Amp)
N/A
N/A
N/A
N/A
N/A
N/A

Efficiency (%)

N/A
>65%
N/A
N/A
>65%
N/A

Power Factor

N/A
N/A
N/A
N/A
N/A
N/A

Leakage Current (mA)

0.25mA (at 60HZ)
N/A
N/A
N/A
N/A
N/A

Maximum Inrush Current (A peak)

N/A
No component was damaged and input fuse shall not blow
N/A
N/A
No component was damaged and input fuse shall not blow
N/A

Maximum Inrush Current duration (mS)

N/A
N/A
N/A
N/A
N/A
N/A
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

System Specifications

  Power **
HP ProLiant ML110 G4 Fully Configured (see **)
Fully Loaded System output Wattage (W) 370W
Fully Loaded System Input Current (A rms) 8A @ 115V, 4A @ 230V
Fully Loaded System Thermal (BTU- Hr) 1907BTU
Fully Loaded System VA (Volt-Amp) 920
System Leakage with all power supplies loaded (mA) 0.75mA@240V
0.45mA@120V
System Inrush Current with all power supplies loaded (A) 80A
Power cord requirements Nema 5-15P to IEC320-C13
IEC320-C13 to IEC320-C14
**Power shown is for a fully configured system consisting of (1) CPU, (4) double-sided DIMMs, (4) HDDs, (1) CD-ROM, (1) DVD-ROM, (4) PCI cards, and (1) power supply.
Power Cords (13 Cord Sets) Power Cord Part Number
Country
APD 100614-009, 100613-008, 139867-004, 187487-004 (India)
Brazil 285052-001
Australia 100661-001
Euro 100614-009
France 100614-009
Germany 100614-009
Japan 139867-004
PRC 286496-001
UK 100613-008
US, Taiwan 121565-001
contents
 Overview      Standard Features      Models      Configuration Information-Factory Integrated Models      ML110 G4 Options      Service and Support, HP Care Pack, and Warranty Information      ML110 G4 Memory      Storage      Power Specifications      System Specifications      ML110 G4 QuickSpecs images/line.gif

Quickspecs

System Unit Dimensions (HxWxD)
(with feet)
14.46 x 6.88 x 16.76 in (36.7 x 17.5 x 42.6 cm)
Weight (approximate) 23.15 lb (10.5 kg)
Input Requirements
(per power supply)

Range Input Voltage

100 to 127 VAC/200 to 240 VAC
Normal Line Voltage 115 or 230 VAC
Line Frequency 50 to 60 Hz
Rated Input Current load 8A at 115VAC, 4A at 230VAC
BTU Rating 1907 BTU
SCSI Connectors
(SCSI Models only)
One internal LVD/SE connector for U160 devices, plus two internal SE connectors for legacy devices.
Power Supply Output Power
(per power supply)
Rated Steady-State Power 370W
Maximum Peak Power 370W
Temperature Range Operating 50° to 95° F (10° to 35° C)
Shipping -40° to 140° F (-40° to 60° C)
Relative Humidity
(non-condensing)
Operating 10% to 90%
Non-operating 10% to 90%
Acoustic Noise Idle
(Fixed Disk Drives Spinning)

L WAd (BELS)
5.5
Operating
(Random Seeks to Fixed Disks)

L WAd (BELS)
6.0

HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD
411275-B21 411275-B21
160GB 7,200 rpm

Capacity 160,041 MB
Height 1.0 in. (26.1 mm)
Width 4.0 in. (101.6 mm)
Interface Serial ATA
Transfer rate synchronous (maximum) 1.5 Gb/s
Seek time (typical reads, including settling) Single track 0.9 ms
Average 9.0 ms
Full-stroke 17.8 ms
Rotational speed 7,200 rpm
Physical Configuration Bytes/Sector 512
Logical Blocks 312,581,808
Operating Temperature 41° to 131° F (5° to 55° C)

NHP 72GB 3G SAS 15K 3.5" HDD
431950-B21 431950-B21
72GB 15K

Capacity 73,407,856,856
Height 1.0 in (25.4mm)
Width 4.0 in. (101.6 mm)
Interface SAS
Transfer rate synchronous (maximum) 3 Gb/sec
Seek time (typical reads, including settling) Single track 0.27 ms
Average 3.5 ms
Full-stroke 3.5 ms
Rotational speed 15,000 rpm
Physical Configuration Bytes/Sector 512
Logical Blocks 143,374,737
Operating Temperature 50° to 95° F (10° to 35° C)

48X Max IDE (ATAPI) CD-ROM Drive
398972-B21
Disk Applicable Disk CD-ROM, CD-XA, CD-DA
(Mode 1, Mode 2, Form 1 and 2)
Photo CD (Single and Multi-session)
Mixed Mode (Audio and Data combined)
CD-R
Capacity 540MB (Mode 1, 12 cm)
650MB (Mode 2, 12 cm)
Block Size Mode 1 2,048 bytes, 1024 bytes
Mode 2 2,340 bytes, 2,336 bytes, 1024 bytes
CD-DA 2,352 bytes
CD-XA 2,328 bytes
Interface IDE (ATAPI)
Access Times (typical) Random <100 ms
Full-Stroke <150 ms
Data Transfer Rate Sustained 3000 to 7750 KB/s (20X to 48X)
Burst 150 KBps to 7,200 KBps
Bus Rate 16.7 MBps
Cache Buffer 128 KB
Start-up Time (typical) < 7 seconds
Stop Time < 4 seconds
Laser Parameters Type Semiconductor Laser GaA1As
Wave Length 780 ± 25 nm
Operating Conditions Temperature 41° to 122° F (5° to 50° C)
Humidity 10% to 90%
Dimensions

(HxWxD, maximum)

1.63 x 5.75 x 7.87 in (41.3 x 146 x 200 cm)
Weight 2.64 lb (1.2 kg)

4 port Embedded SATA controller SATA Protocol SATA 1.5Gb/s
SATA Ports 4 internal
Port transfer rate 1.5 Gb/s total
Maximum Capacity up to 2 TB (4 x 500GB non hot plug SATA HDD)
RAID Levels Supported RAID 1+0 (Striping & Mirroring)
RAID 1 (Mirroring)
RAID 0 (Striping)
Logical RAID Volumes Supported

Embedded NC320i PCIe Gigabit Server Adapter

Network Interface 10Base-T/100Base-TX/1000Base-TX
Compatibility IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
Data Transfer Method Single lane (x1), 100MHz PCI Express Reference Clock
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
1000Base-TX (Half and Full-Duplex) 2000Mb/s
Connector RJ-45 connector
Cable Support 10Base-T Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
10/100/1000Base-TX Category 5 UTP; up to 328 ft (100 m)

Environment-friendly Products and Approach

End-of-life Management and Recycling

Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to https://www.hp.com/go/green. To recycle your product, please go to: https://www.hp.com/go/green or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: https://www.hp.com/go/green. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.


Sillworks                  Ph: 1.613.599.1287                  Fax: 1.613.599.8120
U320 | SSD | SAS/SATA | Fibre | Memory | Controllers | Processors | Power Supplies | Networking
line
Dell | EqualLogic | EMC | Hewlett-Packard | IBM | Seagate
line
HP      HP      HP      Dell Home | Shopping Cart | Delivery | Forgot Password | Order By Phone | Create an Account Dell      Dell      Dell      Seagate
Terms of Use | Legal | Privacy | Primary Site | Contact us | Add to favorites
Amex Accepted Visa Accepted MasterCard Accepted
